Megger Baker 12kV Static Motor Analyzer AWA-IV/12 is a fully-automated motor analyzer that automatically performs repeatable, user-programmable tests to thoroughly assess the strength of a motor’s insulation and circuit.

Megger Baker 12kV Static Motor Analyzer AWA-IV/12 Surge test:

• Output voltage 0 to 12 000 V
• Max output current 600 A
• Pulse energy 2,88 J
• Storage capacitance 0,04 µF
• Sweep range 2,5 to 200 µs/Div
• Volts division 250/500/1 000/2 000
• Repetition rate 5 Hz
• Voltage measurement and accuracy ± 12 %

Megger Baker 12kV Static Motor Analyzer AWA-IV/12DC Hipot test:

• Output voltage 0 to 12 000 V
• Max output current 10 000 µA 5 000 µA 5 000 µA 5 000 µA 10 000 µA
• Current resolution 0,1, 1, 10, 100 µA/Div
• Over-current trip settings (factor @ 0,8) 1, 10, 100, 1 000 µA
• Full scale voltage and current measurement and accuracy ± 5 %
• MΩ accuracy ± 10 %
• Max MΩ reading >50 000 MΩ
• Resistance measurements 0,001 to 800 Ω
