| brand | Hubbell Chance |
|---|---|
| model | T403-2398PE |
Product Details
The Hubbell Chance T403-2398 16kv Dual-Range Phasing Tester easily determines phase relationships and approximate voltage, line-to-line or line-to-ground. Each tester consists of two fiberglass poles with end fittings threaded for interchangeable probes. The probe fittings couple with a high-impedance component encased in each pole. To complete the test circuit, a 22-foot length of insulated flexible cable stores on the reel affixed to one pole and connects to the voltmeter on the other pole. Simple to operate, the tester poles first attach to two 6-foot Epoxiglas® insulating universal handles (included in each kit for proper working clearances). Then the probes can be brought into contact with the conductors appropriate for the meter to read phase-to-phase or phase-to-ground voltage.
Hubbell Chance T403-2398 16kv Dual-Range Phasing Tester features & applications:
- Determine phase relationships and approximate voltage, line-to-line or line-to-ground
- Feature two fiberglass poles with end fittings threaded for interchangeable probes
- Probe fittings couple with a high-impedance component encased in each pole
- To complete test circuit, a 22 ft. length of insulated flexible cable stores on reel affixed to one pole and connects to voltmeter on other pole
- Simple to operate, tester poles first attach to two 6 ft. Epoxiglas insulating universal handles (included in each kit for proper working clearances)
- Probes can be brought into contact with conductors appropriate for the meter to read phase-to-phase or phase-to-ground voltage
